Android 控件之ImageSwitcher图片切换器

ImageSwitcher是Android中控制图片展示效果的一个控件,如:幻灯片效果...,颇有感觉啊。做相册一绝

一、重要方法

setImageURI(Uri uri):设置图片地址

setImageResource(int resid):设置图片资源库

setImageDrawable(Drawable drawable):绘制图片

二、实例

  <ImageSwitcher android:id="@+id/switcher"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:layout_alignParentTop="true"
        android:layout_alignParentLeft="true"
    />

    <Gallery android:id="@+id/gallery"
        android:background="#55000000"
        android:layout_width="match_parent"
        android:layout_height="60dp"
        android:layout_alignParentBottom="true"
        android:layout_alignParentLeft="true"

        android:gravity="center_vertical"
        android:spacing="16dp"
    />
is = (ImageSwitcher) findViewById(R.id.switcher);
is.setFactory(this);

设置动画效果

is.setInAnimation(AnimationUtils.loadAnimation(this,
android.R.anim.fade_in));
is.setOutAnimation(AnimationUtils.loadAnimation(this,
android.R.anim.fade_out));

三、完整代码

1.布局文件

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <ImageSwitcher android:id="@+id/switcher"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:layout_alignParentTop="true"
        android:layout_alignParentLeft="true"
    />

    <Gallery android:id="@+id/gallery"
        android:background="#55000000"
        android:layout_width="match_parent"
        android:layout_height="60dp"
        android:layout_alignParentBottom="true"
        android:layout_alignParentLeft="true"

        android:gravity="center_vertical"
        android:spacing="16dp"
    />
</RelativeLayout>

2.Java代码

package wjq.WidgetDemo;
import android.app.Activity;
import android.content.Context;
import android.os.Bundle;
import android.view.View;
import android.view.ViewGroup;
import android.view.Window;
import android.view.animation.AnimationUtils;
import android.widget.AdapterView;
import android.widget.BaseAdapter;
import android.widget.Gallery;
import android.widget.ImageSwitcher;
import android.widget.ImageView;
import android.widget.AdapterView.OnItemClickListener;
import android.widget.AdapterView.OnItemSelectedListener;
import android.widget.Gallery.LayoutParams;
import android.widget.ViewSwitcher.ViewFactory;

public class ImageSwitcherDemo extends Activity implements OnItemSelectedListener, ViewFactory {
    private ImageSwitcher is;
    private Gallery gallery;
    private Integer[] mThumbIds = {R.drawable.b, R.drawable.c, R.drawable.d, R.drawable.f, R.drawable.g,};
    private Integer[] mImageIds = {R.drawable.b, R.drawable.c, R.drawable.d, R.drawable.f, R.drawable.g,};

    /*
     * (non-Javadoc)
     *
     * @see android.app.Activity#onCreate(android.os.Bundle)
     */
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        // TODO Auto-generated method stub
        super.onCreate(savedInstanceState);
        requestWindowFeature(Window.FEATURE_NO_TITLE);
        setContentView(R.layout.imageswitcherpage);
        is = (ImageSwitcher) findViewById(R.id.switcher);
        is.setFactory(this);
        is.setInAnimation(AnimationUtils.loadAnimation(this,android.R.anim.fade_in));
        is.setOutAnimation(AnimationUtils.loadAnimation(this,android.R.anim.fade_out));
        gallery = (Gallery) findViewById(R.id.gallery);
        gallery.setAdapter(new ImageAdapter(this));
        gallery.setOnItemSelectedListener(this);
    }

    @Override
    public View makeView() {
        ImageView i = new ImageView(this);
        i.setBackgroundColor(0xFF000000);
        i.setScaleType(ImageView.ScaleType.FIT_CENTER);
        i.setLayoutParams(new ImageSwitcher.LayoutParams(LayoutParams.MATCH_PARENT, LayoutParams.MATCH_PARENT));
        return i;
    }

    public class ImageAdapter extends BaseAdapter {
        public ImageAdapter(Context c) {
            mContext = c;
        }

        public int getCount() {
            return mThumbIds.length;
        }

        public Object getItem(int position) {
            return position;
        }

        public long getItemId(int position) {
            return position;
        }

        public View getView(int position, View convertView, ViewGroup parent) {
            ImageView i = new ImageView(mContext);
            i.setImageResource(mThumbIds[position]);
            i.setAdjustViewBounds(true);
            i.setLayoutParams(new Gallery.LayoutParams(LayoutParams.WRAP_CONTENT, LayoutParams.WRAP_CONTENT));
            i.setBackgroundResource(R.drawable.e);
            return i;
        }

        private Context mContext;
    }

    @Override
    public void onItemSelected(AdapterView<?> parent, View view, int position, long id) {
        is.setImageResource(mImageIds[position]);
    }

    @Override
    public void onNothingSelected(AdapterView<?> parent) {
        // TODO Auto-generated method stub
    }
}
